Power Range: 3 HP to 35 HP
Stages: 4 Stage to 25 Stage (modular setup)
Borewell Outer Diameter: 150 mm (6-inch)
Power Supply: SINGLE PHASE (160-240V),THREE PHASE(200-415V),ESC(250-415V)
Design: V6 Motor base connected to V6 high-flow Model pump head
1. What is a V6 Mixed Flow Submersible Pump?
- A high-discharge pump designed for 6-inch (150 mm) or larger borewells, utilizing a mixed-flow impeller design where water flows both axially and radially for maximum volume delivery.
2. What is the power range (HP) for V6 Mixed Flow pumps?
- They typically range from 3 HP to 35 HP in three-phase power setups.
3. How does Mixed Flow differ from Radial Flow in V6 pumps?
- Mixed Flow: Delivers higher volume/discharge of water at medium head depths (ideal for open fields and flood irrigation).
- Radial Flow: Delivers higher head/pressure to push water from much deeper borewells, but with lower discharge volume.
4. What are the key features of V6 Mixed Flow pumps?
- High Discharge Rate: Engineered to move large quantities of water quickly.
- Robust Build: Cast iron or stainless steel bowls/impellers with water-lubricated motor bearings.
- Sand & Wear Resistance: Designed with specialized sleeves and bush bearings to handle sandy/dirty borewell conditions.
5. Where are V6 Mixed Flow pumps best suited?
- Agricultural flood irrigation, crop spraying, and canal lifting.
- Large commercial farms and village water supply schemes.
- Drip and sprinkler systems requiring heavy water flow.
