Power Range: 5 HP to 30 HP
Stages: 2 Stage to 12 Stage (modular setup)
Borewell Outer Diameter: 165 mm (7-inch)
Power Supply: SINGLE PHASE (160-240V), THREE PHASE(200-415V), ESC(250-415V)
Design: V6 Motor base connected to V7 high-flow pump head
1. What is a V7 Submersible Pump?
A V7 submersible pump is designed for installation in 7-inch (175 mm) borewells or open wells. It bridges the gap between smaller V6 pumps and larger V8 pumps, offering higher water discharge for medium to deep groundwater levels.
2. What is the usual power rating (HP range)?
- HP Range: Typically 2 HP to 15 HP (available in both single-phase and three-phase models).
3. What flow design types are available?
- Radial Flow: Ideal for high head (lifting water from deeper wells).
- Mixed Flow: Ideal for high discharge (delivering large volumes of water at medium depths).
4. Where are V7 pumps commonly used?
- Agricultural irrigation (drip, sprinkler, flood irrigation).
- Commercial and industrial water supply.
- Community water supply schemes and rural groundwater lift.
5. What are the key features and benefits?
- Water-Lubricated Motor: Quiet, efficient, and low-maintenance operation.
- Wide Voltage Operation: Designed to start and run effectively under voltage fluctuations common in rural areas.
- Durable Construction: Typically built with Stainless Steel motor bodies and Cast Iron or SS impellers for long service life.
