Stages: 5 Stage to 50 Stage (modular setup)
Borewell Outer Diameter: 100 mm (4-inch)
Power Supply: SINGLE PHASE (150-230V),THREE PHASE(200-415V),ESC(200-415V)
Design: V4 Motor base connected to V4 high-flow Model pump head
V4 Submersible Pump — Frequently Asked Questions
1. What is a V4 Submersible Pump?
A V4 submersible pump is a 4-inch diameter water pump designed to operate fully submerged inside 4-inch (or larger) borewells, open wells, and underground sumps.
2. What power range and applications is it suitable for?
- Power Range: Typically available from 0.5 HP to 5.0 HP.
- Applications: Ideal for residential homes, apartment complexes, small-scale agricultural farms, garden irrigation, and overhead tank filling.
3. What power supply options are available?
V4 pumps are available in both Single-Phase (220V/230V) for domestic/light-commercial use and Three-Phase (415V) for farm or heavy-duty use.
4. What is the difference between Radial Flow and Mixed Flow V4 pumps?
- Radial Flow: Engineered for higher head (depth) with moderate discharge—best for deeper borewells.
- Mixed Flow: Engineered for higher water discharge (volume) at shallow to medium depths—best for maximum water output.
5. Can a V4 pump handle sand or muddy water?
Standard V4 pumps work best with clear water. However, models fitted with high-grade Noryl or stainless steel impellers and anti-sand wear plates can tolerate small amounts of suspended sand particles.
6. What essential protection is needed during installation?
Always pair the pump with a reliable starter panel featuring overload protection, low voltage cut-off, and dry-run protection to prevent motor burnouts.
